Engineered according to DIN 345 standards, the ILIX 6114 features a Morse taper shank and reinforced geometry for improved stability during heavy-duty drilling operations. Its optimized design enhances tool life and cutting performance, making it ideal for professional workshops requiring reliable accuracy when machining difficult materials and high-strength alloys.
6631 Twist Drill VA DIN 345 Series ILIX
With a 130° point angle and robust construction, the ILIX 6114 VA drill ensures efficient chip evacuation and reduced cutting forces. The cobalt-alloy composition improves wear resistance at elevated temperatures, supporting consistent performance even in intensive machining processes involving stainless steel, special steels, and non-ferrous metals under industrial production conditions.
Features
Overview
| Specification | Details |
|---|---|
| Product Series | 6114 VA |
| Standard | DIN 345 |
| Tool Material | HSS-Co |
| Point Angle | 130° |
| Drill Length Ratio | Approx. 8×D |
| Diameter Range | ~10 mm to 32 mm |
| Tolerance | h8 |
| Shank Type | Morse taper |
| Application Materials | Stainless steel, alloy steel, cast iron, non-ferrous metals, titanium |
| Cooling | External cooling / conventional |
