LED Illuminated Mangifire LED-OSL-3 Otsuka Optics
The Otsuka Optics LED-OSL-3 is a long-bar LED illuminated magnifier that clamps securely to a workbench. It offers bright, energy-efficient LED lighting with roughly half the power consumption of comparable fluorescent models, while maintaining the same illumination and diffusion quality for extended visual inspection tasks.
26 people are viewing this product right now
🔥 11 items sold in last 3 hours
Designed for industrial and laboratory use, the LED-OSL-3 features a large square optical glass lens that reduces edge distortion and supports prolonged inspection. Its head-mounted ON/OFF switch and flexible X/Y bar arrangement provide ease of operation and limited free-arm movement for positioning over workpieces.
LED Illuminated Mangifire LED-OSL-3 Otsuka Optics
The LED-OSL-3 from Otsuka Optics delivers crisp LED illumination and fixed magnification with optional OSL-PUL power-up lens to increase magnification from 2× to 4×. The AC adapter-powered design is ideal for bench-based electronics, quality control, and detailed visual inspection environments.
Features
Overview
| Lens | |
|---|---|
| Magnification | 2x, 4x |
| Allowable lens dimension (mm) | 100×140 |
| Lens Material | Optical glass |
| Working distance (mm) | 2x/160, 4x/110 |
| Lens Type | Fixed |
| Multi-coating Setting | Not available |
| Lighting | |
| Light source | White LEDs 2 pcs. |
| Wavelength | 400 nm |
| Input voltage | 100〜240V: 50/60 Hz: Plug Type A |
| Power consumption | 9W |
| Dimming Function | Not available |
| Body | |
| Product weight | 2X: 2.9kg / 4X: 3.9kg |
| Overall height (mm) | 355 |
| Head Dimensions (mm) | 180X237 |
| Virtical/Horizontal Bar(diameter/mm) | ɸ16/ɸ13 |
| Clamping width (mm) | 15 to 60 |
| AC adapter dimensions (mm) | 64x50x27 |
