Equipped with high-precision flow sensors, multi-pressure ranges (positive and negative gauge), and programmable test sequences, the 615 handles zeroing, filling, stabilizing, measuring and venting without external regulators. Its real-time data-processing, large program memory, and detailed statistics provide thorough insights for test engineers.
CETATEST 615 Flow Tester
The Sylvac S_CAL EVO BASIC caliper combines robust construction with smart design,
featuring a 3.5 mm thick stainless steel frame and IP67 rating for durability.
Features
Overview
| Specification | Detail / Value |
|---|---|
| Device Type | Fully automatic mass flow tester for large volume parts; leak detection via thermal mass flow. |
| Measurement Ranges (Examples) | Sensor type 1: 0-10 ml/min, 0-25 ml/min, 10-600 ml/min. Sensor type 2: –20 to +20 ml/min. Additional ranges available upon request. |
| Display Resolution | 0.01 ml/min display resolution in small ranges. |
| Pressure Ranges | 200 mbar, 1 bar, 2 bar, 6 bar, 10 bar; positive and negative gauge pressures; combined ranges possible. |
| Accuracy / Maximum Deviation | For gauge pressure: ± 1 % of full scale. Mass flow sensor type 1: ± 1 % FS. Type 2: in forward direction: 0.2-5 ml/min: ± 0.5 %; >5-20 ml/min: ± 2 %. Backward direction: 0.2-2 ml/min: ± 0.5 %; >2-20 ml/min: ± 5 %. |
| Pneumatic Requirements | Compressed air supply 6-10 bar; test pressure air (or reservoir) at 0.5 bar above test pressure; evacuation pressure option. Fittings: input 6 mm plug-in; test/reservoir ports 8 × 1 mm. |
| Signal / Electronics | 24-bit A/D converter; 16-bit microcontroller 40 MHz; real-time signal processing. |
| Program / User Memory | 64 parameterizable test programs with alpha-numeric names; export/import via USB; password protected user levels. |
| Power Supply | 100-240 V AC, 47-63 Hz; power draw up to 60 W depending on configuration. |
| Dimensions / Weight | 345 × 145 × 435 mm (3U rack height); 10 kg. |
| Warranty | 3 years with annual maintenance; optional extension to 5 years. |
