MIRUC Optical Stages / Optical Staging (Dovetail / Feed-Screw Stages etc.)
MIRUC Optical dovetail stages are precision sliding positioning units designed for long-stroke, smooth action with excellent load resistance. Available in rack and pinion or feed screw drive types, these stages support flexible combinations and fine adjustment using pre-load tuning, suitable for FA and industrial tooling applications.
34 people are viewing this product right now
🔥 12 items sold in last 3 hours
The multi-function feed screw stages from MIRUC offer selectable travel per handle rotation (2 mm / 5 mm / 10 mm), long-stroke movement, and smooth sliding action. Their modular design allows symmetrical configurations and optional handle types, making them ideal for precision positioning in space-limited applications.
MIRUC Optical Stages / Optical Staging (Dovetail / Feed-Screw Stages etc.)
MIRUC’s slide operation dovetail stages are patented, thin, and lightweight units with rapid manual slide movement and tool-less adjustment. Featuring a detachable sliding block and simplified mechanism, they deliver high accuracy, reduced cost, and easy integration into inspection or measurement equipment.
Features
Overview
| Specification | Value |
|---|---|
| Stage Type | Dovetail / Feed Screw / Slide Operation |
| Drive Type | Rack & Pinion, Feed Screw, Manual Slide |
| Stage Surface | e.g., 25×40 mm – 60×60 mm (varies by series) |
| Travel Range | ±6 mm – ±57 mm (model dependent) |
| Load Capacity | 9.8 N – 39.2 N depending on series |
| Travel Precision | 30 µm typical (slide and feed screw) |
| Material | Aluminum Alloy with Satin Black Anodized Finish |
| Weight | 23 g – 450 g depending on model |
