The SK Series Skeleton Stage from Miruc offers reliable fine positioning with ±21 mm travel and an easy-to-read 0.1 mm scale. Constructed from acrylic, polycarbonate, and polyacetal materials, it provides an ultra-light slide solution with maintenance-free operation for optical setups, lab automation, and environments where traditional metal stages fail.

Miruc Skeleton Stage SK Series

Miruc’s Skeleton Stage is engineered for applications requiring non-metallic, grease-free motion. This compact slide unit features smooth operation without lubrication, strong structural resilience, and multiple color options for visual identification of risk or process importance. It’s less than half the weight of an aluminum stage with stable mechanical performance.

Features

Non-metallic Construction

Made from resin materials (acrylic, polycarbonate, polyacetal) to avoid metal-related issues like rust or magnetism.

Grease-Free Smooth Sliding

Self-lubricating plastic surface ensures consistent smooth motion without lubricant.

Corrosion & Weather Resistance

Withstands wet, dusty, or outdoor environments without degradation.

Ultra-Lightweight Design

Significantly lighter than aluminum stages, reducing mechanical load.

Visual Color Identification

Available in skeleton color variations to indicate importance, danger, or process stage.

Overview

Specification	Value
Model Variants	SK-60C, SK-60R, SK-60B, SK-60Y
Stage Surface	40 × 60 mm
Travel (Stroke)	±21 mm
Travel per Rotation	18 mm per handle turn
Movement Accuracy	Straightness 30 µm, Parallelism 30 µm
Load Capacity	19.6 N (2.0 kgf)
Minimum Scale Reading	0.1 mm
Weight	0.11 kg
Materials	Acrylic, Polycarbonate, Polyacetal
Strightness / Derajat Paralel	±0,1 mm
Bahan	Acrylic, Polikarbonate, Polyacetal
