Chennai Metco Auto Cold Cutting Baincut XXL

Chennai Metco Auto Cold Cutting Baincut XXL

The Chennai Metco Auto Cold Cutting Baincut XXL is a heavy-duty automatic abrasive cutter for large specimens up to 180 mm diameter. Powered by a 25 HP, 3-phase motor, with a 20-inch (500 mm) cut-off wheel, and equipped with hydraulic automation plus automatic Z-axis movement. It features a large coolant tank, safety hood and fume extraction for clean, safe operation.

17 people are viewing this product right now

🔥 8 items sold in last 3 hours

Category: Sectioning

Brand: Chennai Estimated delivery:June 22, 2026 - June 24, 2026

Description

Built for demanding metallographic sectioning, the Baincut XXL Auto handles tougher materials (metals, ceramics, mineral grades) with minimal microstructural alteration. It includes a light alloy cast base, FRP corrosion-protected hood, viewing window, cleaning hose, safety lock, and fume digestion system. The machine’s big specimen chamber ensures big parts are locked in securely with reduced vibration. Spindle speed varies from ~1000 to 3000 rpm; the machine offers automatic “Z” movement, hydraulic automation, and a large coolant system for continuous use.

Chennai Metco Auto Cold Cutting Baincut XXL

For labs or workshops needing large-scale sectioning, the Baincut XXL Auto delivers both capacity and protection. With a 500 mm cut-off wheel, 25 HP motor, and cutting capacity up to 180 mm, it’s designed for large pieces. Safety features include hood, fume extraction, safety lock, and viewing window. The table (500 × 500 mm with 12 mm T-slots) plus coolant tank (~130 L) supports smooth heavy-duty operations while variable speed control helps avoid heat damage.

Features

High Cutting Capacity (180 mm diameter)

Can cut large specimens up to 180 mm dia, accommodating bigger samples than typical cutters.

Powerful Motor (25 HP, 3-Phase)

Strong 3-phase 25 HP drive to manage heavy-duty cutting, especially with large diameter wheels under load.

Automatic Z-Axis Movement + Hydraulic Automation

Automatically moves the wheel downward (Z movement) for cutting instead of manual lowering; hydraulic automation improves ease, consistency, and reduces operator fatigue.

Variable Spindle Speed (1000-3000 RPM)

Allows adjusting speed based on material hardness and desired finish, helps reducing heat damage and improving cut quality.

Large Coolant System & Safety Features

Equipped with a large coolant tank (≈ 130 L), coolant tank cooling, fume extraction, hood, safety lock, viewing window, cleaning hose; all to ensure safe, clean, cool operation even under continuous heavy workloads.

Overview

Specification	Detail
Product Name	Chennai Metco Auto Cold Cutting Baincut XXL Auto
Cutting Capacity	Up to 180 mm diameter specimen
Motor Power	25 HP, 3-phase motor
Wheel (Cut-off) Diameter	20″ (500 mm)
Spindle Speed	1000 – 3000 RPM
Table Size	500 × 500 mm with 12 mm T-slots
Coolant Tank Capacity	130 liters
Safety & Protection	Light alloy casting base, FRP hood, viewing window, cleaning hose, safety lock, fume digestion/extraction system
Dimensions (Machine Size)	2225 × 1860 × 2025 mm (L × W × H)
