Annn Yang Machine Center AY-VM-2000
Annn Yang Vertical Machining Center AY‑VM‑2000 is a large‑format CNC machining center built for heavy and precision milling tasks. Its robust structure and extended travel axes allow machining of large workpieces with enhanced accuracy, making it suitable for automotive, aerospace, and industrial fabrications.
11 people are viewing this product right now
🔥 8 items sold in last 3 hours
The AY‑VM‑2000 CNC vertical machining center offers a spacious working envelope with long X and Z axis travel, ample table area, and high spindle speed for versatile milling operations. Its design ensures rigidity and stable cutting performance under heavy load conditions.
Annn Yang machine center ay-vm-2000
Designed for demanding production workshops, the Annn Yang AY‑VM‑2000 combines CNC automation with large travel range and powerful spindle capacity. It supports precision milling, drilling, and complex machining of medium to large components with consistent repeatability.
Features
Overview
| Specification | Value |
|---|---|
| Model | AY-VM-2000 |
| Table Working Surface | 2200 × 800 mm |
| T-Slot (size × number × pitch) | 22 × 6 × P125 |
| Max Table Load | 2000 kg |
| Travel (X × Y × Z) | 2000 × 750 × 700 mm |
| Distance Spindle End to Table | 150 mm |
| Max Cutting Diameter | 2000 mm |
| Max Cutting Length | 550 mm |
| Spindle Nose / Taper | HSK-E40 |
| Spindle Speed Options | 24,000 / 30,000 rpm |
| Bed Type / Guideway | 55 linear guideway |
| Rapid Travel (X / Y / Z) | 30 m/min |
| Cutting Feed Rate | 1 – 8000 mm/min |
| ATC Tool Storage | 30 / 60 tools (nearest tool change) |
| Max Tool Diameter | 125 mm |
| Max Tool Length | 350 mm |
| Max Tool Weight | 15 kg |
| Motor (Spindle) | 18 kW (for 24,000 rpm) / 10 kW (for 30,000 rpm) |
| Machine Size (L × W × H) | 5000 × 4100 × 4400 mm |
| Net Weight | 25,000 kg |
