Vertical Bandsaw LP25-250-6A
Servo Feed System
Table Variant With Rollers on The Inner Table
System Control / Plate Editor
Features of The Automatic Vertical Bandsaw LPS25-250-6A
Technical Data Automatic Vertical Bandsaw LPS25-250-6A
| Cutting Range | |
| Cutting length | 6,100 mm |
| Cutting width | 2,500 mm |
| Cutting height | 250 mm |
| Minimum cutting width | 30 mm |
| Minimum cutting height | 8 mm |
| Performance Characteristics | |
| Drive power | 7.5 kW |
| Blade speed | 10 – 110 m/min |
| Saw blade dimensions | 10,490 x 54 x 1.6 mm |
| Inside table: | |
| Supporting area | 2,800 x 6,250 mm |
| Outside table: | |
| Supporting area | 2,800 x 6,250 mm |
| Number of grippers | 3 |
| Gripper stroke | 2,850 mm |
| Dimensions and Weight | |
| Length | 10,250 mm |
| Width | 8,400 mm |
| Height | 3,900 mm |
| Weight | 28,000 kg |
| Material support height | 1,620 mm |
