Magnetic Drills Element 75 Rotabroach

The Element 75 is a robust mag drill built for heavy-duty tasks, boasting a 1800W motor with two-speed gearbox for drilling 75mm diameter and depth holes. Featuring Cutsmart technology and dual motor protection, it ensures extended tool life with enhanced cooling and cabling systems, offering versatility and reliability for diverse projects.

16 people are viewing this product right now

🔥 5 items sold in last 3 hours

Category: Magnetic Drill

Estimated delivery:June 15, 2026 - June 17, 2026

Description

Magnetic Drills Element 75 Rotabroach

The Element 75 by Rotabroach features an 1800W motor and two-speed gearbox, drilling up to 75mm in diameter and depth. It offers forward/reverse capacities, swivel and non-swivel options, Cutsmart technology, and dual motor protection for versatile, high-performance drilling.

Key Features

For heavy-duty operations the ‘Element 75’ is a must for drilling larger holes. Suitable for drilling up to 75mm diameter by 75mm depth.

Compact, durable and more portable than other larger machines.

The ‘Element 75’ offers forward and reverse functionality.

Supplied as either a swivel base or a non-swivel option.

Quick release interchangeable handle – allowing you to operate the mag drill from either side and improving accessibility.

CutSmart Technology – designed to protect your motor and cutter, prolonging tool life.

Dual motor protection system to prolong the machine’s life and prevent unwanted wear.

13mm drill chuck that can be used for twist drills.

Internal cabling removed the risk of damage and downtime for your magdrill.

Internal cooling – keeping your mag drill cool and allowing you to drill for longer.

Extremely lightweight for ease of use 11kg.

Element Range

Powerful 1800w motor with a two speed mechanical gearbox.

23.5kg: Lighter and more compact than other heavy-duty drills.

Suitable for drilling up to 75mm diameter by 75mm depth.

CutSmart Technology – designed to protect your motor and cutter, prolonging tool life.

Quick release interchangeable handle – allowing you to operate the mag drill from either side and improving accessibility.

Internal cabling reduces the risk of damage and downtime for your magdrill.

Internal cooling – keeping your mag drill cool and allowing you to drill for longer.

Features a swivel base.

Twist drill, threading and countersinking capabilities.

Dual motor protection, minimising wear and downtime of this magdrill.

Specification

Model Number	Element 75/1 / Element 75/3
Motor Specification	110V 1800W / 230V 1800W
No load RPM	Low Gear: 70 -180 RPM / High Gear: 200-500 RPM
Max Hole Cutting Capacity	ø75 x 75mm Deep – 26mm with MT Drill
Overall Dimension	Height: 545mm / Width: 230mm with Capstan / Length: 460mm with Guard
Machine Weight	23.5kg
Magnetic Adhesion	18,500N
Magnet Size	220mm x 114mm
Safety Features	Cutsmart™ Technology / Fixed Guard / Magnetic Detection / Mechanical Clutch
