XT3 Digital Bore Gauge Set With Bluetooth Metric Bowers

The Bowers XT3 Digital Bore Gauge Set with Bluetooth offers ergonomic design and IP67 electronics. Featuring a clear LCD display, 2-button operation, and 4 preset memories. It provides accurate 2-point/3-point measurements, with tungsten carbide faces, blind bore measurement, and optional extensions.

39 people are viewing this product right now

🔥 9 items sold in last 3 hours

Category: Measurement

Estimated delivery:June 16, 2026 - June 18, 2026

Description

XT3 Digital Bore Gauge Set With Bluetooth Metric Bowers

Bowers’ XT3 digital internal micrometers offer a new ergonomic design – including a larger and clearer LCD display – along with IP67 electronics protection, proximity output with built-in Bluetooth; both allow bi-directional communication giving greater flexibility for data acquisition and storage.

Features

New ergonomic design with larger and clearer LCD display.

IP67 electronics.

Simple 2-button operation.

4 preset memories.

Proximity output with optional built-in Bluetooth.

Bi-directional communication.

RS-232C output.

Range 2-300mm (0.080”-12”).

2-6mm 2 point/ 6-300mm 3 point measurement.

Enhanced Efficiency

Resolution 0.001mm/0.00005”.

Tungsten carbide measuring faces on all 3-point heads from 12.5mm.

Blind bore measurement from 2mm - 6mm and above 12.5mm (0.500”).

Extensions available above 6mm for deep hole measurement.

Ratchet stop to ensure consistent measurement.

Setting rings included with individual instruments and sets.

UKAS certificates supplied as standard with all setting rings.

UKAS certificates supplied as standard with all gauges.

Serial number on all digital readouts and measuring heads.

Heads with special anvils available to suit specific customer requirements .

Bore gauges manufactured according to DIN 863, part 4.

Spesification

Product Code	Range (mm)	Measuring Heads	Setting Ring (mm)	Notes	Price
SXTD1M-BT	2-6	5	3		POA
SXTD3M-BT	6-10	2			POA
SXTD4M-BT	10-20	3	2		POA
SXTD5M-BT	20-50	3	2		POA
SXTD6M-BT	50-100	3	2		POA
SXTD7M-BT	100-150	2	1		POA
SXTD8M-BT	150-200	2	1		POA
SXTD9M-BT	100-200	4	2		POA
