Tachometers PT-120 Shimpo
The Shimpo PT-120 Tachometer features metric or imperial models with a 3-unit selection switch. Its lightweight, ergonomic design ensures comfort, while the large backlit LCD offers easy viewing. It records key values and up to 96 data points, with quick review via the MEM button. Contact wheel and cone adapters included.
12 people are viewing this product right now
🔥 5 items sold in last 3 hours
Tachometers PT-120 Shimpo
The SHIMPO Model PT-120 Contact Tachometer is a simple to use, ergonomic, rugged test instrument for rotational speed applications.
This velocity analyzing and measuring device is ideal for rotational machine inspection and process speed analysis. The PT-120 possesses a large backlit LCD screen that provides clear viewing in any environment.
Features
Specifications
| Model | PT-120 |
| Range | PT-122: 0.5-19,999 RPM, 0.05-1999.9 m/min, 0.05-99,999 m; PT-121: 0.5-19,999 RPM, 0.16-6559.6 ft/min, 0.16-99,999 ft |
| Resolution | 0.1 RPM (0.5-999.9 RPM), 1 RPM (above 1000 RPM) 0.01 m/min (0.05-99.99 m/min), 0.1 m/min (100+ up m/min) 0.02 m (0.05-99,999 m) 0.03 ft/min (0.16-99.99 ft/min), 0.3 ft/min (100 ft/min and up) 0.04 ft (0.16-99,999 ft) |
| Display | 5 digit, 0.7” (18 mm) LCD |
| Sampling Time | 0.8 second (over 60 RPM) |
| Accuracy | +/-0.05% + 1 digit |
| Memory | Automatically stores Maximum (UP), Minimum (dn), last value (LA) and up to 96 readings for review. Maximum speed for reading storage is every 0.8 seconds |
| Dimensions | 6.7 x 2.8 x 1.4 (170 x 70 x 35 mm) |
| Power | 3 x 1.5V AAA battery |
| Enclosure | ABS plastic housing |
| Product Weight | 0.45 lb (0.20 kg) |
| Package Weight | 1.00 lb (0.45 kg) |
| Certifications | CE |
| Warranty | 1-Year |
| Included Accessories | 3 AAA batteries, protective carrying case. Large & small cone adapter, funnel, surface wheel, 3.87” (98.3 mm) cir. |
